Frame I Tilt Window

Use:

The tilt window is often used where the possibility of ventilation is desired, but where there are not necessarily requirements for passage, typically in basement or bathroom applications. Frame I / Nation I (inward opening) and Frame IC / Nation IC (outward opening) have the same outer sash-frame height and can therefore be placed in the same elevation, without there being much visual difference. The choice of tilt windows can allow for greater width of the opening.



Function:

The tilt window is an inward opening window with a bottom-hung function. The opening function is controlled by a handle and espagnolette located in the side or top sash. In the closed position, the handle faces vertically downwards (or horizontally) and the tilt function is triggered by turning the handle 90 °. With tilt function, the upper edge of the sash moves approx. 10 cm inwards and gives a free opening of approx. 2.5 cm.

  • Product information:
  • Eref: +2,9 (Medi g) | +13,3 (High g)
  • Uw: 0,82 (Medi g) | 0,85 (High g)
  • Glass dimensions: Triple glazing (48 mm): 4-18-4-18-4
  • Styling bar: 22/23 mm og 42 mm
  • Frame dimensions: 50 x 122 / 149 mm
  • Drawings

  • Min./Max. Dimensions

  • Accessories

  • Manuals
